LTC4L-LIGHT TOWER,LOMBARDINI
LTC4L Fuel System Diagram
- screw - 5000159473×6
- seal - 5000160209×1
- NUT-FLANGED - 5000063700×2
- washer - 5000082285×2
- STUD - 5000084119×2
- PUMP-FUEL - 5000155706×1
- GASKET - 5000087254×1
- PISTON-PUMP - 5000227601×1
- O-RING - 5000110759×1
- 95000159339Not stockedFuel pump rod×1
- O-RING - 5000159237×6
- NUT M8 - 5000082140×6
- 125000159332Not stockedThreaded bolt×6
- washer - 5000082285×6
- ROD-PUSH - 5000159246×3
- VALVE-BLEED - 5000159464×3
- 185000155707Not stockedFuel cock×3
- PLUNGER - 5000155708×3
- spring - 5000159317×3
- PUMP-INJECTION - 5000155709×3
- 275000160332Not stockedSpacer×3
- 275000160342Not stockedSpacer×3
- 275000160341Not stockedSpacer×3
- 275000160340Not stockedSpacer×3
- 275000160339Not stockedSpacer×3
- 275000160338Not stockedSpacer×3
- 275000160337Not stockedSpacer×3
- 275000160336Not stockedSpacer×3
- 275000160335Not stockedSpacer×3
- 275000160334Not stockedSpacer×3
- 275000160333Not stockedSpacer×3
- 285000159313Not stockedSpring-pressure×3
- 295000159247Not stockedRod×3
- SPACER - 5000159278×3
- SCREW M4 X 12 - 5000159471×12
- spark arrester - 5000159318×3
- O-ring - 5000159233×3
- 425000159286Not stockedNut×3
- JET-NOZZLE - 5000155710×3
- FITTING-BANJO BOLT - 5000082105×2
- Copper washer D14/10.2 1 - 5000082183×2
- Copper washer D14/10.2 1 - 5000082183×2
- FITTING-BANJO BOLT - 5000082105×1
- VALVE-ELECTRO,FUEL SHUT-OFF - 5000155711×1
- HOLDER-FUEL FILTER - 5000155712×1
- Copper washer D14/10.2 1 - 5000082183×2
- WASHER-COPPER - 5000082185×2
- HOSE-FROM EL.VALVE TO DEL.LINE - 5000155713×1
- HOSE-FROM FUEL PUMP TO FILTER - 5000155714×1
- 565000155715Not stockedFuel filter cartridge×1
- WASHER-COPPER - 5000159300×3
- WASHER-COPPER - 5000082185×2
- FITTING-BANJO BOLT - 5000082107×1
- O-RING 25 X 12 X 1.78 - 5000159238×3
- GASKET - 5000159302×3
- Pipe - 5000159459×1
- SCREW M10 X 22 - 5000082100×2
- WASHER-DIA. 10 - 5000160231×2
- WASHER DIAM.8 - 5000160235×2
- washer - 5000160236×1
- SCREW M8 X 20 - 5000160363×2
- CONNECTOR-HOSE - 5000159342×1
