LBA1 120V 60HZ BALLOON ONLY
LBA1 Equipment Mount cpl. Diagram
- BRACKET-RECEIVER,WELD - 5000183208×1
- BRACKET-BASE - 5000183209×1
- 35000183210Not stockedClamp bracket×1
- 45000183211Not stockedKnob×4
- 55000183212Not stockedLocking pin×1
- SCREW M10 X 75 HX.HD. - 5000011325×4
- WASHER B10.5 FLAT - 5000010621×10
- WASHER-LOCK B10 - 5000010644×6
- NUT M10 8,HEX - 5000010883×4
- SCREW M10 X 25 HX.HD. - 5000011440×2
- 115000183218Not stockedHexagon nut×4
- POLE-WELDMENT - 5000183246×1
- LABEL-SHEET,LIGHT BALLOON - 5000181494×1
- 155000183213Not stockedMount×1
