GP3800A-PORTABLE GENERATOR

GP3800A Control Panel cpl. Diagram

Exploded parts diagram of the Control Panel cpl. of a Wacker Neuson GP3800A, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 315000163909Not stocked
    Control panel w/label×1
  • 325000163868Not stocked
    Circuit breaker×1
  • 345000161013Price
    SWITCH-4PDT - 5000161013×1
  • 355000162739Price
    SWITCH-ROCKER,SPST - 5000162739×1
  • 365000161309Not stocked
    Switch×1
  • 385000089849Not stocked
    GFI Receptacle Kit×2
  • 405000082948Price
    RECEPTACLE 30A, 125V - 5000082948×1
  • 415000161015Price
    RECEPTACLE,L14-20 20A - 5000161015×1
  • 425000165596Not stocked
    Auto Idle Module Kit×1
  • 1105000162264Price
    SCREW M3X6,PPHMS CL4.8,BL.C - 5000162264×4
  • 1125000162712Price
    SCREW M6X10,SBHD,FLGE 10.9,BC - 5000162712×10
  • 1485000010370Price
    NUT-LOCK M4 HEX. - 5000010370×13
