G2.1AE SCHUKO GENERATOR
G2.1AE Crankshaft/Piston/Flywheel Diagram
- CAP-ROTATOR,ENGINE VALVE - 5000070998×1
- HOLDER-EXHAUST SPRING - 5000070997×1
- SPRING-ENGINE VALVE - 5000081760×2
- 45000082006Not stockedExhaust valve×1
- VALVE-INTAKE - 5000082005×1
- Cup spring - 5000070996×1
- CAMSHAFT - 5000073266×1
- SPRING-WEIGHT RETURN - 5000151028×1
- TAPPET-VALVE,ENGINE - 5000070990×2
- ROD-PUSH - 5000071637×2
- PLATE - 5000073265×1
- STUD-ROCKER ARM PIVOT - 5000072778×2
- ROCKER ARM-VALVE,ENGINE - 5000070986×2
- PIVOT-ROCKER ARM - 5000070985×2
- NUT 1/4-28,PIVOT ADJUSTMENT - 5000070984×2
- CRANKSHAFT-COMPLETE - 5000084640×1
- GEAR - 5000071642×1
- GEAR - 5000071643×1
- SET-PISTON RINGS,STANDARD - 5000081995×1
- CLIP-PISTON PIN - 5000081994×2
- PISTON-STANDARD - 5000082004×1
- Connecting Rod - 5000071647×1
- SCREW M7 X 35,ACORN HD,CL.12 - 5000071007×2
- PIN-PISTON MOUNT - 5000071648×1
- CAP-SPARK PLUG TERMINAL - 5000070974×1
- 265000070973Not stockedIgnition coil×1
- 275000071651Not stockedMagneto flywheel×1
- WEDGE 25 X 18 - 5000068967×1
- FAN - 5000071652×1
- PULLEY-STARTER - 5000081779×1
- NUT M14 - 5000054005×1
- SCREW M6 X 25, FLANGED - 5000081737×2
