G180 Generator, T3 Sunbelt Custom
G180 Option-Positive Air Shutoff Diagram
- ENCLOSURE-BOX PAS - 5200008459×1
- BRACKET-REVGUARD - 5200008532×1
- BRACKET,PAS SWITCH - 5200008470×1
- HARNESS-PAS,G100/120 T3 - 5200008471×1
- STRAIN RELIEF 3/4 NPT - 5200009121×1
- SCREW M6 X 10 HX.HD. - 5000012356×1
- WASHER B6.4 FLAT - 5000010624×1
- SCREW M5X25 SOC.HD BL ZN 10.9 - 5000163951×4
- SWITCH - PAS XL MGs - 5200014688×1
- 125200014689Not stockedBreaker×1
- PIPE-CAC,INTAKE G100/120 PAS - 5200008458×1
- SCREW M5 X 12 SOC.HD. - 5000043307×4
- HOSE-REDUCER,SILICONE,3-2.25 - 5200008472×2
- VALVE-BUTTERFLY,AMOT RDB3 - 5200008455×1
- 5625200008457Not stockedIntake pipe×1
- CLAMP-2 5/8 NOM,T-BOLT - 5000156290×2
- 5655000028699Not stockedClamp×2
- REVGUARD-AMOT CONTROL BOX, PAS - 5200008456×1
- SCREW M4 X 16 SOC.HD. - 5000011570×2
