FUH35/2/042

FUH35/2/042 Frequency Converters Diagram

Exploded parts diagram of the Frequency Converters of a Wacker Neuson FUH35/2/042, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15100047677Not stocked
    Bottom plate×1
  • 45100045021Not stocked
    Handle×1
  • 55100048208Not stocked
    Power supply cable with plug×1
  • 65000201214Price
    WIRE-GROUND - 5000201214×1
  • 75100048369Not stocked
    Ground wire cpl.×1
  • 105000010367Price
    NUT-LOCK M8 HEX - 5000010367×2
  • 115000011538Price
    SCREW M8 X 45 SOC.HD. - 5000011538×2
  • 125000011573Price
    SCREW M4 X 8 SOC.HD. - 5000011573×3
  • 145100049930Not stocked
    Electric wire cpl.×2
  • 155000200988Price
    WASHER-LOCK,TOOTHED - 5000200988×4
  • 165100049748Not stocked
    Cheese head screw×9
  • 185000010872Price
    NUT M4 8,HEX. - 5000010872×1
  • 195000127289Price
    NUT-COUNTER - 5000127289×1
