DW40
DW40 wiring harness STVO option Diagram
- 11000425683Not stockedwiring harness×1
- 21000425685Not stockedwiring harness×1
- 31000027384Not stockedround socket sleeve×2
- 41000027431Not stockedbushing housing×5
- 51000027438Not stockedbushing housing×1
- 61000027442Not stockedwedge×1
- 71000027445Not stockedpin housing×1
- 81000027449Not stockedhousing×1
- 91000030446Not stockedplug×13
- Pin housing - 1000085023×1
- locking pin - 1000085026×1
- plug locking - 1000085032×5
- CABLE LUG - 1000096859×2
- Pin housing - 1000105117×2
- wedge - 1000105118×2
- 161000309282Not stockedpin contact×4
- 171000309284Not stockedbushing contact×6
- 181000359612Not stockedplug connection×16
- 191000362407Not stockedpin contact×17
- 201000375997Not stockedfixing bracket×2
- 211000322839Not stockedfixing bracket×1
