DPU100-70Le Reversible Vibratory Plate
DPU100-70LES Exciter cpl. Diagram
- 15000105785Not stockedExciter housing×1
- Eccentric shaft - 5000220166×1
- Piston - 5000220141×1
- PIN-TRIPPING - 5000096980×1
- 55000066166Not stockedCylindrical roller bearing×4
- adjusting sleeve - 5000126701×1
- Bushing - 5000096982×2
- Washer - 5000097151×2
- Cylinder - 5000220121×1
- Adjustment cylinder - 5000220142×1
- SHAFT-ECCENTRIC - 5000097154×1
- WEIGHT-ECCENTRIC - 5000105861×2
- WEIGHT-ECCENTRIC - 5000105862×2
- WASHER-LOCK HS12,HIGH TENSION - 5000021465×8
- SCREW M12X45 SC.H.GR10.9,PLAIN - 5000049203×8
- SCREW M6 X 22 SOC.HD. - 5000012373×15
- flange - 5000129185×1
- Hydraulic motor - 5000220436×1
- SCREW M6 X 25 SOC.HD. - 5000011550×5
- WASHER-FLAT,M8,ZINC - 5000010622×4
- 225000096994Not stockedGear wheel×1
- KEY A12 X 8 X 28 - 5002006603×1
- Piping - 5000220279×1
- CLAMP-PIPE - 5000096691×2
- SCREW M8 X 16 SOC.HD. - 5000011544×2
- FITTING-FLANGED ELBOW - 5000067412×1
- 305000220149Not stockedFlange×1
- FITTING-PIPE L15R - 5000046093×1
- SCREW M8 X 22 SOC.HD. - 5000012629×4
- O-Ring - 5000220451×1
- SCREW M6 X 40 SOC.HD. - 5000011547×5
- SCREW M6 X 30 SOC.HD. - 5000011549×2
- SCREW M6 X 20 SOC.HD. - 5000011551×4
- COVER-VENT - 5000096649×1
- SCREW - 5001103030×1
