DPS3060Hv
DPS3060HV Air Ducting Diagram
- COVER-HOOD - 5000108836×1
- WASHER-SPRING 6 A3C - 5000151456×6
- DISC (RUBBER SLEEVE) - 5000129520×2
- NUT-HEX M6 8 A3C - 5000151323×6
- DUCT-AIR - 5000108839×1
- SEAL - 5000108841×1
- Grommet - 5000107379×1
- SLEEVE-RUBBER - 5000108842×4
- WASHER 4.3,A3C,140HV - 5000108843×3
- SCREW-HEX M4 X 10 - 5000108844×3
- SCREW-M6X16-8.8,A3C,KL360G - 5000202304×3
- SCREW-ALLEN, M6X16 - 5000151231×1
- WASHER-FLAT 6.4 - 5000151324×2
- 175000107493Not stockedBlind grommet×1
- 185000108845Not stockedRubber funnel×1
- TUBE-SPACING 6.5X12X18 - 5000108852×5
- 225000129502Not stockedBaffle plate×1
- DUCT-AIR - 5000129491×1
- SEAL - 5000108841×1
- SEAL-STRIP 470MM - 5000108855×1
- SEAL-STRIP 388MM - 5000108857×1
- SCREW-ALLEN HD,M6X25-8.8 A3C - 5000129010×1
- RING-SEALING - 5000107800×3
- SPACER-BUSHING - 5000209664×3
- SLEEVE-RUBBER - 5000108838×1
- BRACKET-SUPPORT - 5000108847×1
- 345000108846Not stockedScrew×1
- SCREW M6X12, 10.9, A3C - 5000126983×1
- WASHER-LOCK A8 - 5000013601×1
- Nut - 5000108848×1
- WASHER-SPRING 6 A3C - 5000151456×1
- STUD M6X45,8.8 A3C - 5000108850×2
- SEAL-STRIP 48MM - 5000108856×1
- WASHER 6.5 X 22.5 X 1 - 5000108851×1
- TUBE-SPACING 6.5X12X18 - 5000108852×2
- CAP - 5000202307×1
- CLIP-SPRING - 5000129513×1
- DISC - 5000151482×2
- Washer - 5000107261×1
- HOUSING-BLOWER - 5000108837×1
- Clamp - 5000097590×1
- Label - 5000215783×1
