CT24-4A Trowel

CT24-4A Fuel Tank cpl. Diagram

Exploded parts diagram of the Fuel Tank cpl. of a Wacker Neuson CT24-4A, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000081764Price
    hose cover - 5000081764×1
  • 45000071083Price
    FILTER-FUEL,INTANK - 5000071083×1
  • 55000216515Not stocked
    Fuel tank×1
  • 65000209769Price
    FUEL CAP - 5000209769×1
  • 75000209770Price
    Gasket - 5000209770×1
  • 95000209771Price
    BOLT-FLANGE 6 X 29 - 5000209771×1
  • 115000071082Price
    O-RING 14 X 1.3 - 5000071082×1
  • 125000071056Price
    NUT M6,HEX,FLANGE - 5000071056×2
  • 155000209773Price
    HOSE-FUEL(4.5 X 140) - 5000209773×1
  • 155000213412Price
    HOSE-FUEL(4.5 X 3000) - 5000213412×1
  • 165000054136Price
    CLAMP B8,HOSE CLIP - 5000054136×2
  • 175000208617Price
    CLAMP-TUBE - 5000208617×1
