BV50A-P BACKPAK (SPM3+PH45),EU
BV50A-PEU Mount cpl. Diagram
- 25000174885Not stockedEngine mount×1
- BELT-SUPPORT - 5000174783×1
- NUT-NYLOCK 1/4-20 - 5000174833×1
- 115000174870Not stockedHexagonal head cap screw×2
- WASHER-LOCK M8 - 5000174805×2
- 135000174887Not stockedHexagonal head cap screw×1
- 145000174804Not stockedSpring washer×4
- BOLT-HEX M6 X 10 - 5000174806×3
- 205000174784Not stockedBolt×3
- 215000174785Not stockedFlat washer×6
- 225000174836Not stockedNut×3
- 235000174848Not stockedSupport bracket×2
- SCREW M6 1.0 X 40,HEX - 5000157766×2
- 255000174862Not stockedFender washer×1
- NUT-NYLOCK M6 - 5000174808×1
- CLAMP 3.16 - 5000174787×2
- 445000174859Not stockedShroud×1
- 465000174881Not stockedMounting bracket×1
- 475000174821Not stockedBolt×2
- 485000174835Not stockedFlat washer×4
- 495000174858Not stockedShockmount×2
- 505000174882Not stockedBolt×2
- NUT-NYLOCK 3.8-16 - 5000174831×2
- 525000174878Not stockedShockmount×2
- 535000174883Not stockedBushing×2
- 545000174799Not stockedBushing×8
- 555000174862Not stockedFender washer×8
- 565000174861Not stockedBolt×4
- 575000174836Not stockedNut×4
