BS60-4 RAMMER,11 PL SHOE

BS60-4 Guide Handle cpl. Diagram

Exploded parts diagram of the Guide Handle cpl. of a Wacker Neuson BS60-4, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 125000156377Not stocked
    Guide handle×1
  • 145000182368Price
    KIT-FUEL TANK W/OUT VENT - 5000182368×1
  • 155000182306Not stocked
    Inner cable casing×1
  • 175000118148Price
    CONTROL-THROTTLE - 5000118148×1
  • 855000011341Price
    SCREW M8 X 40 HX.HD. - 5000011341×1
  • 975000010622Price
    WASHER-FLAT,M8,ZINC - 5000010622×1
  • 995000010624Price
    WASHER B6.4 FLAT - 5000010624×2
  • 1155002005049Price
    HOSE-FUEL 3/16 X 16.50 - 5002005049×1
  • 1205000105194Price
    WASHER M8 X 1.5 - 5000105194×1
  • 1305000177408Price
    COVER-SILENCING,4-C,YL RAL1021 - 5000177408×1
  • 1525000157115Price
    BRACKET-THROTTLE - 5000157115×1
  • 1575000086312Price
    SEAL-RING - 5000086312×1
  • 1585000114066Price
    KIT-FUEL VALVE W/BUSHING - 5000114066×1
  • 1595000112179Price
    KIT-FUEL FILTER W/BUSHING - 5000112179×1
  • 1605000163682Not stocked
    Fuel tank cap×1
  • 1615000173019Price
    CAP-LANYARD - 5000173019×1
  • 1625000110586Not stocked
    Bushing spacer×1
  • 1635000173020Price
    Gasket - 5000173020×1
  • 1765000155774Not stocked
    Outer casing×1
  • 1795000160861Price
    SCREW M6X16 SC HD,W/WASHER,SEM - 5000160861×8
  • 2155000118112Price
    PLATE-THROTTLE STOP - 5000118112×1
  • 2325000011553Price
    SCREW M6 X 16 SOC.HD. - 5000011553×2
  • 2735000172305Price
    NUT-LOCK M8 HEX,AUTO,CLASS 9 - 5000172305×1
